Semi-Automatic Electronic Net Weight Filling Machine - Model PWF-1S | Electric Panel

Request a Quote

STRUCTURE & CHASSIS | PRESSURE CAP SYSTEM |

CONVEYOR SYSTEM | ELECTRIC PANEL

Item	Part No.	Part Name	Price
2	ELS-422111	Hinges, CFA. 49 B-M5
4	PWF-S-TRI-4-750-B-2-X1-16A	Trim Seal, 750 Series, 1/16 edge, 7/16 leg black
6	PWF-S-736	PWF Control indicator sheet
8	DBR-E5-6-005-UU1	Cam latch
10	AEL-ABB-OHYS2AJ	N3R Disc with handle
12	PWF-S-710	Control panel door
14	DBR-E5-8018	Cam latch grip 1.34
16	AEL-ABB-S2C-DH	Mini breaker mechanism
18	WAY-24602	Dome nut, Thread size: 1/2 NPT

Item	Part No.	Part Name	Price
20	CAI-10X-09-022	Disconect plate
22	PC1-8000-03-02	Breaker plate
24	PWF-S-704E	Control panel cover
26	AEL-WA-210-112	Steel carrier rail, 35 mm X 7.5 mm X 1 mm
28	MCM-8302K192	Liquid-Tight Cord Grip, for 0.63"-0.75" OD, 3/4" Size
30	PWF-S-702E	Control panel structure base
32	AEL-53-NB5QTW00B	5.6in, TFT LCD, color,320234 dots
34	AEL-QQ-9111	POT, SPEED, Conductive Plastic Pot, 5k
36	LEE-POTENTIOMETER	Control Knob for potentiometer

Item	Part No.	Part Name	Price
38	AEL-60-D7-X01	NC contact
40	AEL-60-D7-ALP	Mounting latch
42	AEL-60-D7P-MT44	Emergency Stop Push Button
44	AEL-EO-M22-DDL-GR-GB	2-function momentary button
46	AEL-60-D7P-LF5	Green illuminated push button
48	AEL-60-D7-X10	NO contact
50	AEL-60-D7-N3G	Green illuminated LED module 24VAC
52	PWF-A-T1-1022G-02	Thin finger duct grey 1PC, 2M with cover

Item	Part No.	Part Name	Price
54	AEL-QQ-9979	1 HP AC Drive, 115/230VAC, 1 Phase, 50/60 Hz
56	AEL-EO-XTCE018C10TD	3 Pole FVNR contactor 18 Amp
58	AEL-53-S8VKC06024	Power supply 60W, 24VDC 2.5A 100-240VAC
60	AEL-WA-857-304	ELECTRICAL TRM BLK DC 24V, 10MA
62	AEL-WA-282128-281417	2-Conductor fuse terminal block for glass fuses 1/4 x 1 1/4
64	PWF-S-AEL-WA-210-112-01	Steel carrier rail, 35 X 7.5 mm, 1mm/0.039 in thick slotted
66	PWF-A-T1-1022G-01	Thin finger duct grey 1PC, 2M with cover
68	PWF-S-852	Pail weight panel components sheet

Item	Part No.	Part Name	Price
70	PWF-S-AEL-WA-210-112-02	Steel carrier rail, 35 X 7.5 mm, 1mm/0.039 in thick slotted
72	AEL-WA-280-907	2-Conductor through terminal block (Ground)
74	AEL-WA-280-901	2-Conductor through terminal block
76	AEL-WA-282-312	End an int plate, Height 46.4 mm, Width 4 mm
78	AEL-53-CP1LL20DRA	PLC with 20 I/O, Volt: 100 to 240 VAC
