Highly Corrosive Product Rotary Pressure Overflow Filler RF48-01|Nozzle Cam System

$ 0.00 USD

Product variants

Item	Part No.	Part Name
2	RF48-09-020	Acme Threaded Rod Support PT2015
4	APL-R10ZZ	Bearing R10ZZ
6	RF48-09-018	Acme Threaded Rod Support B PT2015
8	RF48-09-042-1	Sprocket 40-14 Teeth, 1.25in
10	ROL-RC40NP-1R-10FT-59	Roller Chain, 10 Foot Box" Pitch: 0.500
12	RF48-05-122	Sprocket 40-22 Teeth, 1.25 in ROF-48`
14	RF48-09-036-2	Height Adjust Crank Handle Shaft 036 ROF-48
16	RF48-09-022-B	7208 BEP Housing Ring
18	MSC-67153288	External Retaining Ring 0,75 in
20	SKF-7208 BEP	Bearing, Single Row, ID 40mm, OD 80mm

Item	Part No.	Part Name
22	RF48-09-040	Sprocket 40-16 Teeth, 1.25 in
24	RF48-09-014-1	Height Adjust Crank Handle Shaft 014 ROF-48
26	RF48-09-012	Threaded Rod PT2015
28	RF48-09-024	Chain Tensor Plate ROF-48
30	APL-MBB-R12ZZ	Bearing R12ZZ
32	RF48-09-026-1	Height Adjust Crank
34	RF48-09-016-1	Threaded UHMW Plastic Nut PT2015
36	RF48-09-074	Sprocket 40-60 Teeth, 1in ID, 1045 Steel Coated
38	AME-HNX-16	Hexagon Nut 1-8
40	ROL-RC40NP-1R-10FT-210	Roller Chain, 10 Foot Box" Pitch: 0.500

Item	Part No.	Part Name
42	RF48-09-004E	ROF48 Nozzle Elevation Guide
44	RF48-09-082	Drip Tray Height Adapter A Support
46	RF48-09-080	Single Rotary Nozzle Guide Bracket Separator
48	RF48-09-002E	RF Cam Corrosive Resistant
50	RF48-09-076	Single Rotary Nozzle Guide Bracket Separator
52	M1-6753601	External Retaining Ring 1,25
54	RF48-09-078	Single Rotary Nozzle Guide Bracket
56	RF48-09-028	Sprocket 40-14 Teeth, 1.25in
58	C2F104SS	Two Bolt Flange Unit-Composite-st/st Insert-1.25in
60	RF48-09-008	Single Roller Height Adjustment Assy

Item	Part No.	Part Name
62	RF48-09-032	Height Adjust Crank Handle Separator ROF-48
64	RF48-09-010	ROF48 Nozzle Elevation Separator A
66	Radial Seal 1.25x2x0.25	Radial shaft seal, 1.50 ID 2 OD x 0.25
68	RF48-09-058 B	Bearing Housing Cap Corrosive Resistant
70	MCM-3760T252	Kynar Single Row Bearing Glass Ball
72	RF48-09-006	Cam and Elevation Guide System Plate
74	RF48-01-068	Housing Kynar 2.25in Radial Bearing
76	RF48-09-030	Height Adjust Crank Handle Shaft ROF-48
78	RF48-09-100	Crank Handle With Fold Away Handle
80	RF48-09-050	Drip Tray Height Adapter A
82	RF48-09-054	Bottle Belts Key
84	RF48-09-052	Belts Transmission Shaft 1
86	RF48-09-048	RF48 Anticorrosive Drip Tray
88	MCM-45375K521	Thick-Wall White PTFE Threaded Fitting
