Semi-Automatic Electronic Net Weight Filling Machine - Model PWF-1S | Electric Panel
$ 0.00 USD
/
STRUCTURE & CHASSIS | PRESSURE CAP SYSTEM |
CONVEYOR SYSTEM | ELECTRIC PANEL
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 2 | ELS-422111 |
Hinges, CFA. 49 B-M5 |
|
| 4 | PWF-S-TRI-4-750-B-2-X1-16A | Trim Seal, 750 Series, 1/16 edge, 7/16 leg black |  |
| 6 | PWF-S-736 |
PWF Control indicator sheet |
|
| 8 | DBR-E5-6-005-UU1 | Cam latch | |
| 10 | AEL-ABB-OHYS2AJ | N3R Disc with handle | |
| 12 | PWF-S-710 | Control panel door | |
| 14 | DBR-E5-8018 | Cam latch grip 1.34 | |
| 16 | AEL-ABB-S2C-DH | Mini breaker mechanism | |
| 18 | WAY-24602 | Dome nut, Thread size: 1/2 NPT |
|
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 20 | CAI-10X-09-022 |
Disconect plate |
|
| 22 | PC1-8000-03-02 | Breaker plate | |
| 24 | PWF-S-704E |
Control panel cover |
|
| 26 | AEL-WA-210-112 | Steel carrier rail, 35 mm X 7.5 mm X 1 mm | |
| 28 | MCM-8302K192 | Liquid-Tight Cord Grip, for 0.63"-0.75" OD, 3/4" Size | |
| 30 | PWF-S-702E | Control panel structure base | |
| 32 | AEL-53-NB5QTW00B | 5.6in, TFT LCD, color,320234 dots | |
| 34 | AEL-QQ-9111 | POT, SPEED, Conductive Plastic Pot, 5k | |
| 36 | LEE-POTENTIOMETER | Control Knob for potentiometer |
|
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 38 | AEL-60-D7-X01 |
NC contact |
|
| 40 | AEL-60-D7-ALP | Mounting latch | |
| 42 |
AEL-60-D7P-MT44 |
Emergency Stop Push Button |
|
| 44 | AEL-EO-M22-DDL-GR-GB | 2-function momentary button | |
| 46 |
AEL-60-D7P-LF5 |
Green illuminated push button | |
| 48 | AEL-60-D7-X10 | NO contact | |
| 50 |
AEL-60-D7-N3G |
Green illuminated LED module 24VAC | |
| 52 | PWF-A-T1-1022G-02 | Thin finger duct grey 1PC, 2M with cover | |
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 54 | AEL-QQ-9979 |
1 HP AC Drive, 115/230VAC, 1 Phase, 50/60 Hz |
|
| 56 | AEL-EO-XTCE018C10TD | 3 Pole FVNR contactor 18 Amp | |
| 58 | AEL-53-S8VKC06024 |
Power supply 60W, 24VDC 2.5A 100-240VAC |
|
| 60 | AEL-WA-857-304 | ELECTRICAL TRM BLK DC 24V, 10MA | |
| 62 | AEL-WA-282128-281417 | 2-Conductor fuse terminal block for glass fuses 1/4 x 1 1/4 | |
| 64 | PWF-S-AEL-WA-210-112-01 | Steel carrier rail, 35 X 7.5 mm, 1mm/0.039 in thick slotted | |
| 66 |
PWF-A-T1-1022G-01 |
Thin finger duct grey 1PC, 2M with cover | |
| 68 | PWF-S-852 | Pail weight panel components sheet | |
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 70 | PWF-S-AEL-WA-210-112-02 |
Steel carrier rail, 35 X 7.5 mm, 1mm/0.039 in thick slotted |
|
| 72 | AEL-WA-280-907 | 2-Conductor through terminal block (Ground) | |
| 74 |
AEL-WA-280-901 |
2-Conductor through terminal block |
|
| 76 | AEL-WA-282-312 | End an int plate, Height 46.4 mm, Width 4 mm | |
| 78 |
AEL-53-CP1LL20DRA |
PLC with 20 I/O, Volt: 100 to 240 VAC | |
