Piston Filler - Model Trupiston-8-Hor Tube Structure & Chassis

Request a Quote

TUBE STRUCTURE & CHASSIS | PISTON & VALVE SYSTEM

ELECTRIC PANEL TOUCH | TANKS

Item	Part No.	Part Name	Price
2	GI3300-01-002	Top support part
4	GI3300-01-017	Bottom movement stop
6	GI3300-01-010	Height nut2
8	GI3300-01-013	Sensor movement top
10	ELS-77511	Handle 7in Round
12	AEL-E2A-M12KS04-WPB1	Height proximity sensor
14	GI3300-01-012	Movement top

Item	Part No.	Part Name	Price
16	GI3300-01-019	Bottom bumper 3
18	GI3300-01-015	Bottom bumper 1
20	GI3300-01-008	Top bumper
22	SKF-M/5201522	2 n linear bearing OD x 1 1/4in ID
24	GI3300-01-014	Main bar
26	GI3300-01-016	1.25 linear bearing housing
28	GI3300-01-026	Nozzle holding bar
30	GI3100-01-004	Scaled height guide
32	SKF-LJXR 20X36 ESSC2	Calibrated shafts

Item	Part No.	Part Name	Price
34	610-290	Nozzle holding square tube
36	GI3300-01-020	Nozzle height threaded rod
38	GI3300-01-034	Calibrated shafts bottom hold
40	610-280	Main trupiston base
42	GI3300-01-038	Radial shaft seal housing
44	610-330	Right cover sheet
46	610-320	Back cover sheet
48	610-360	Tank support separator

Item	Part No.	Part Name	Price
50	610-310	Front cover sheet
52	610-260	Gating tube 1
54	610-030E	Tube structure and chasis
56	GI3300-01-070	Gating rectangles height spacer
58	610-250	Right conveyor bracket
60	610-300	Left cover sheet
62	PU7000-01-038	Gating L 1
64	PU7000-01-036	Gating L 2

Item	Part No.	Part Name	Price
66	610-340	Motor support separator
68	610-350	Motor base
70	610-270	Chassis feet
72	MAC-ACASI-SER-01	Serial Nameplate
76	GI3100-01-078	Chassis cover
76	610-240	Left conveyor bracket
78	APL-MART 16H100	Timing pulley 0.5 pitch, 16 grooves
80	AME-HNX-16	Hexagon nut 1-8

Item	Part No.	Part Name	Price
82	HPE-AS3201FN0307SX35	Inline flow control, panel mount 12mm
84	GI3300-01-068	Gating cylinder width adjustment
88	ADA-SR-122-D	Bimba cylinder 1-1/4" bore
90	Bimba-SR-125-D	Double acting cylinder
92	LEE-120923.00	2 Hp Motor, 1725 RPM, 3 Phase, 220V
94	SW-3-POL-BASE	Poly mount base 3 1-8
96	ADA-922B-RA	Valve Mac 922B-RA
98	FES-159582	Air fliter Festo LFR 0.125 Serie D
100	SMC-NCAY5EO006B1000	Air cylinder 2.5 bore, 10 in stroke
51	M1-36677029	Radial shaft seal 1x1.5x0.25
