Piston Bottle Filler PI3100 | 30GL Standard Tanks
$ 0.00 USD
/
FILLER SYSTEM & CHASSIS | ELECTRIC PANEL STANDARD
TANKS | ACCESORIES | PISTONS
The Piston Bottle Filler PI3100 has two options in tank capacity:
Option A: 30 gallons standard tank
- 30 Gallon 304 Stainless Steel tank for the reception of product to be filled, includes top cover and 3 sanitary 1 ½ inch standard connections
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 2 |
TK3012-01-002 |
Above cover |
 |
| 4 | M1-82504721 |
Straight handle of 5in |
|
| 6 | SEY-51500-1 | 4" 304 Stainless steel float | |
| 8 | GI3100-01-134 | Arm float | |
| 10 | GI3100-01-136 | Clamp arm float | |
| 12 | TK3014-01-004E | Welded pieces assemble | |
| 14 | M1-84424225 | Swivel male elbow 0.125NPT x 0.15625 HOSE | |
| 16 | NUM-LR4-201 | Numatrol valve | |
| 18 | JUI-PLUG-1.5" | Sanitary plug 1.5in | |
| 20 | JUI-CLAMP-1.5" | Sanitary clamp 1.5in | |
| 22 | M1-82288572 | Swivel male elbow 0.25NPT x 0.25 OD | |
| 24 | ADA-AP063BDA,AS7004T | 1" Stainless steel, Sanitary valve | |
| 26 | JUI-GASKET-EPDM-1.5 | Gasket, Size: 1.5in, Material: EPDM | |
| 28 | LAU-75050 | Revolving polyurethane wheel nylon of 50mm | |
