- Gating cylinders to automatically control handling of the bottles.
- Nozzle movement via air cylinder 4in.
- Heavy duty 304 stainless steel frame construction.
- Minimal air consumption.
- All contact parts are stainless steel, sanitary, Teflon, Buna, Viton.
Control panel features:
- Omron PLC for all machine logic functions.
- AC variable speed control for conveyor.
- Conveyor speed control for machine sold with conveyor.
- 3in touch-screen display from Omron.
- The machine can work with 1, 2, 3, 4, 5, 6, 7 or 8 pistons at the same time.
- Front panel Start and Emergency STOP for easy access.
- Fiber optic sensors by Omron standard for container gating.
- No bottle no fill PLC controlled.
- Nozzle spacing fully adjustable.
- Container height adjustment.
- Nozzle stroke adjustments.
- Adjustable entry and exit bottle gating cylinders.
- Works with plastic or glass containers.
- No change parts needed for various types of containers.
- 8 in stroke on each piston, with individual adjustability.
- Stainless steel construction.
- O-rings used as piston seals.
Electric and pneumatic requirements:
- 220 Volts, 60Hz, 5 Amps.
- 5 CFM @ 80 psi.
