Front and Back Labeler Model Tru-Labeler-FB-HH | Conveyor

Request a Quote

TUBE STRUCTURE | CONVEYOR | LABELING HEAD SYSTEM (HERMA HEAD)|CHAIN SYSTEM | INVERTED CONVEYOR | INVERTED CONVEYOR SUPPORT SYSTEM | ELECTRIC PANEL TOUCH | SPACING WHEEL

Item	Part No.	Part Name	Price
2	TRU-L-FB-07-014	Magnet
4	TRU-L-FB-07-004	Conveyor Part B
6	TRU-L-W-01-014	Polyethylene Wear Strips Color For CV 118 in
8	TRU-L-W-01-020	PVC Spacer
10	TRU-L-W-01-016	U Joint Shaft
12	CV-COM-01-010	U Joint Shaft
14	DHP-H820-T21-NO	Idler Wheel Plastic Sprocket, Bore 1 in
16	DHP-H820-K450	Plastic Straight Running Chain 118 in

Item	Part No.	Part Name	Price
18	TRU-L-FB-07-002	Conveyor Part A
20	TRU-L-W-01-004	Stainless Steel Spacer
22	TRU-L-CONV-BR-02	Stainless Steel Conveyor Bracket
24	CV-COM-01-08	Single Clamp
26	LINA-13182	Cross Block 0.50 in x 0.50 in
28	CV-COM-01-004	Width Adjust Shaft
30	CV-COM-01-002	Height Adjust Shaft
32	TRU-L-FB-07-012-1	Reflector Base

Item	Part No.	Part Name	Price
34	TRU-L-W-01-006	Sensor Holder
36	SICK 5304812	Reflector
38	TRU-L-W-01-032E-A	Reflector Support
40	TRU-L-FB-07-042	Support Piece
42	TRU-L-FB-07-048	Tight Seal- Strip Brushes Guide
44	TRU-L-FB-07-046	Tight Seal- Strip Brushes Support
46	TRU-L-FB-07-054	Tight Seal- Strip Brushes Support 1
48	TRU-L-FB-07-056	Tight Seal- Strip Brushes Support 2

Item	Part No.	Part Name	Price
50	TRU-L-FB-07-050	Tight Seal- Strip Brushes Guide
52	TRU-L-FB-07-052	Tight Seal- Strip Brushes Guide
54	MCM-7442T13	Tight Seal- Strip Brushes
56	TRU-L-FB-W-H-07-006	Outer Support
58	PEER-77R16	Radial Ball Bearing, 1 x 2 x 1/2, Shielded
60	TRU-L-W-01-018	Bearing Housing
62	TRU-L-FB-07-036	Separator
64	DHP-H820-T21	Sprocket With Minimum Pilot Bore

Item	Part No.	Part Name	Price
66	TRU-L-FB-07-026	Drive Shaft - 7.5in CV
68	LEE-W5205082.00	Worm Gear Reducer FHMQ520-26-HL-56-16
70	RRU-.5018EP3ERS56C	Motor AC, 1/2 HP, 208V, 1750 RPM, SS56C
72	TRU-L-FB-07-028	Encoder Spacer
74	TRU-L-FB-07-032	Encoder Support
76	CALT GHH60	Encoder
