Construction features:
-
304 Stainless steel heavy duty stainless steel welded C frame.
-
All contact parts are stainless steel, sanitary, Teflon, viton and hoses per your requirements.
-
Special seals or hoses by order.
-
Calibrated guide for fast height changeovers
Control panel features:
- OMRON PLC for all flow meter filler machine logic functions.
- Front & Back panel conveyor speed control for machine sold with conveyor.
- Front & Back panel mounted bottle counter.
- Front & Back panel Start and Emergency STOP for easy access.
- Front & Back panel nozzle code for changing nozzle quantities.
- Fiber optic sensors by Omron standard for container gating.
Main components features:
- Until 12 Flowmeter per lane with an Ultra-Compact Transmitter
- Special Tank 316ss or 304ss
- Level Sensor
- Precision Regulator
- Fast-Acting Pressure-Relief Valve for Air and Inert Gas.
- Entry and exit bottle gating cylinders adjustable, sideways, up and down and inside and outside.
- Will work with plastic or glass containers.
- No change of parts needed for various types of containers.
- Air filter-regulator and safety lockout valve included.
- Spacing and additional bottle control obtained by flow controls mounted on air gating cylinders.
Electric and pneumatic requirements:
- 220 Volts, 60Hz, 15 Amps.
- 20 CFM @ 80 p.s.i.
