Flow Meter Filler Machine Part FMF-4000-01-102B By Acasi Machinery

FMC-7200-006-A

Control Box

+ Quick View

FNS-1050H100 NG-L-1

Timing belt 1050H100 NG-L-1, 210 teeth, pitch 0.5in, width 1in, single sided

+ Quick View

FNS-TN240H100AR

240H100, with 1/4"th., blue lycra covered sponge with rolled edges

+ Quick View

FNS-TN360H100

360H100 w/1/4" blue lycra covered sponge with rolled edges

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB

Main Construction Features:

1500 in/min labeling head
Maximum label height: 7.25in
Heavy duty 304 stainless steel frame
Heavy duty casters standard
No change parts needed for a wide range of containers
Stepper driven
Rolls wind #4
Maximum container width: 6”
Minimum container height: 1/2”
Conveyor: 10ft long, 4.5” wide acetal chain with speed control installed on labeler control panel

Electric and pneumatic requirements:

208 - 240 Volts, Single phase, 50/60Hz, 10 Amps.

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB Part TRU-L-FB-03-008

Conveyor Part B

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB Part TRU-L-FB-03-010

Conveyor Part A

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB Part TRU-L-FB-03-028

Outer Support

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB Part TRU-L-FB-03-040

Outer Support

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB Part TRU-L-FB-07-026

Drive Shaft- 7.5 in CV

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB Part TRU-L-FB-07-028

Encoder Spacer

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB Part TRU-L-FB-07-032

Encoder Support

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB Part TRU-L-FB-07-036

Separator

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB - Drawings

Construction Features:

Heavy duty 304 stainless steel frame
Heavy duty casters standard
No change parts needed for a wide range of containers
Stepper driven
Maximum label size: 152mm H x 300mm L (6” x 11.8”)
Rolls wind #4
Maximum container width: 6”
Minimum container height: 1/2”
Conveyor: 10ft long, 4.5” wide acetal chain with speed control installed on labeler control panel

Electric and pneumatic requirements:

120 Volts, Single phase, 50/60Hz, 15 Amps.

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB - Videos

Construction Features:

Heavy duty 304 stainless steel frame
Heavy duty casters standard
No change parts needed for a wide range of containers
Stepper driven
Maximum label size: 152mm H x 300mm L (6” x 11.8”)
Rolls wind #4
Maximum container width: 6”
Minimum container height: 1/2”
Conveyor: 10ft long, 4.5” wide acetal chain with speed control installed on labeler control panel

Electric and pneumatic requirements:

120 Volts, Single phase, 50/60Hz, 15 Amps.

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB | Electric Panel Touch

Item	Part No.	Part Name
2	AEL-53-NP5MQ001B	HMI 5.7" monochrome
4	AEL-EO-M22-DDL-GR-GB	2-Fuction Momentary Button
6	AEL-60-D7P-MT44	Emergency Stop Push button
7	TRU-L-06-048-B	Board Rectangle for screen and buttons
8	TRU-L-FB-11-002E	Electric Panel Box
10	WAY-24604	Dome Nut 3/4 NPT Thread Size
12	WAY-24602	Dome Nut, Thread Size: 1/2 NPT
14	PC1-8000-03-02	Breaker Plate
16	CAI-10X-09-022	Disconnect Plate
18	AEL-WA-210-112	Steel Carrier Rail, 35mm x 7.5mm x 1mm
22	AEL-ABB-S202U-K15	Miniature Circuit
22	AEL-ABB-S2C-DH	Mini breaker mechanism

Item	Part No.	Part Name
24	AEL-ABB-OXS6X180	Main Switch Shaft
26	DBR-E5-8018	Cam Latch Grip 1.34
28	TRU-TL-06-E-A	Control Panel Door
30	DBR-E5-6-005-UU1	Cam Latch
32	AEL-ABB-OHYS2AJ	Main Switch
34	MAC-ACASI-SER-01	Serial Name Plate
36	ELS-422111	Hinges, CFA. 49 B-M5
38	TRU-L-W-03-022E	Support For Board
40	TRU-L-W-03-026	Cover For Electrical Tube 2
42	TRU-L-W-03-008	Cover For Electrical Tube

Item	Part No.	Part Name
44	AEL-53-3G3MX2AB004V1	AC Drive, 240 V 1PH, 1/2HP 0.4 KW
46	TRU-TL-06-008	Support For Board Electrical Components
48	AUT-T1-1020G	Thin Finger Duct Gray 1 PC, 2M With Cover
50	20753H	Fuse
52	AEL-WA-280-901	2-conductor through terminal block
54	ALT-M0818XMIND	Stepping Motor Drive Boxed X-MIND B6
56	TRU-L-03	Steel Carrier Rail, 35 x 7.5mm, 1mm/0.039in Thick Slotted
58	AEL-EO-XTCE025C10TD	3 Pole contactor 25 AMP, Contac 24VDC coil
62	AEL-WA-282128-281417	2-Conductor Fuse Terminal Block Glass Fuses 1/4 x 1 1/4
64	AEL-53-CP1LL20DRA	Micro PLC With 20 I/O , Voltage: 100/240 VDC. Inputs 18
66	AEL-WA-857-304	Electrical Relay TRM DC 24V, With 1 Changeover Contact

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB | Chain System

Item	Part No.	Part Name
2	TRU-L-FB-09-026	Handwheels KIPP-06263-1080CO
4	TRU-L-FB-09-028	Centering System Cover A
6	MCM-2737T281	Finished-Bore Sprocket For Ansi Roller Chain
8	TRU-L-FB-09-030	Cover Spacer
10	MCM-97345A264	316 Stainless Steel Shoulder Screw
12	MCM-6436K62	Two Piece Clamp on Shaft Collar
14	TRU-L-FB-09-010	316 Stainless Steel Screw
16	M1-06454706	Flange Bronze Sleeve Bearing 0.5 ID X 0.625 OD X 0.5 Length X 0.875 OD
18	MCM-6338K419	Oil-Embedded Flanged Sleeve Bearing
20	TRU-L-FB-09-012	Idler Pulley

Item	Part No.	Part Name
22	M1-35433390	Bearing R8
24	TRU-L-FB-09-006	Chain Guide
26	TRU-L-FB-09-014	Idler Pulley Shaft
28	TRU-L-FB-09-008	Chain Guide Washer
30	TRU-L-FB-09-004	Centering Chain System Base
31	ROL-RC35-1R-50FT	Standard Roller Chain
32	TRU-L-FB-09-024	Vertical Threaded Rod Washer
34	MCM-92383A730	Type 420 Stainless Steel Slotted Spring Pin
36	TRU-L-FB-09-022	Vertical Threaded Rod
38	TRU-L-FB-09-018	Vertical Shaft
40	200340	Tube 28 Bushing Right Hand
42	M1-75368829	Metal Backed Bearing 1" OD, 0.88" ID X 1" L

Item	Part No.	Part Name
44	MCM-5634K590	Comfort- Grip Adjustable Handle
46	BOD-N2227	Gear Motor 1/6 Hp, 94 Rpm, 18:1, 39 Lb-in
48	TRU-L-FB-09-034	Grip Adjustable Handle Screw
50	TRU-L-FB-09-016	Centering Chain System Support A
52	TRU-L-FB-09-038	Horizontal Threaded Rod
54	TRU-L-FB-09-040	Horizontal Shaft
56	M1-75368845	Metal Backed Bushing 1in ID X 0.75 H X 1.125 OD
58	TRU-L-FB-09-042	Grip Adjustable Handle Shaft
60	TRU-L-FB-09-032	Centering Chain Guide System Support B
62	TRU-L-FB-09-028_MIR	Centering System Cover B
64	TRU-L-FB-09-016_MIR	Centering Chain System Support C
66	MCM-92373A179	18-8 Stainless Steel Slotted Spring Pin
68	SPEC S-E-0300-037-1120	Extension Spring

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB | Inverted Conveyor

Item	Part No.	Part Name
2	BOD-2226	Gear Motor 1/6 HP, 57 Rpm, 96 Lb-in
4	TRU-L-FB-01-006	Pressure Belt Sheet A
6	TRU-L-FB-01-040	Cover A
8	TRU-L-FB-01-042	Cover B
10	TRU-L-FB-01-028	Pressure Pin Assembly Support B
12	TRU-L-FB-01-026	Pressure Pin Assembly Support A
14	TRU-L-FB-01-030	UHMW Spacer
16	TRU-L-FB-01-038	Spacer Shaft
18	TRU-L-FB-01-008	Servo R88M_KE20030H_S2 coupling
20	TRU-L-FB-01-020	Idler Pulley Shaft

Item	Part No.	Part Name
22	TRU-L-FB-01-018	Idler Pulley
24	TRU-L-FB-01-010	Traction Pulley
26	TRU-L-FB-01-007	Pressure Belt Sheet B
28	PEER-R16 ZZ	Bearing R16- 0.375 Width
30	MSC-67984641	Cotter Pins Min Size1/4", Max 5/16" Length 1-1/8in
32	C0455-046-1500	Compression Spring, Wire 0.046in OD, Length 1.5in
34	TRU-L-FB-01-024	Pressure Pin
36	TRU-L-FB-01-022	Pressure Pin Base

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB | Inverted Conveyor Support System

Item	Part No.	Part Name
2	M1-03181757	Handwheels KIPP-06263-1080CO
4	SK0917-10, OI-19, 1-O-A	Direct Driver Digital Position Indicator
6	TRU-L-W-05-070	Digital Indicator Support
8	TRU-L-W-05-040	Crank Handle Shaft
10	MCM-92383A726	Clevis Pin
12	MCM-6436K62	Two Piece Clamp on Shaft Collar
14	TRU-L-W-05-030	Crank Handle Shaft Spacer
16	6031-4VBF53	Thrust Ball Bearing 1.000 X 0.500
18	TRU-L-W-05-016	Upper Shaft Support
20	M1-35433390	Bearing R8

Item	Part No.	Part Name
22	TRU-L-W-05-050	Handwheel Screw Holder
24	TRU-L-W-05-046	Tube 28 Bushing Right Hand
26	TRU-L-W-05-052	Bushing Housing
28	TRU-L-FB-02-020	Threaded Rod
30	MCM-98409A240	Internal Retaining Ring for 1-1/4" ID
32	IGU-RJUI-01-12	Plastic Linear Bearing 0.750in OD, 1.250in ID
34	TRU-L-W-05-008	0.75 Linear Bearing Housing
36	TRU-L-FB-01-032	Pressure Belt Support B
38	TRU-L-FB-01-004	Support Tube
40	TRU-L-FB-01-036	Vertical Shaft
42	TRU-L-W-05-006	Lower Shaft Support
44	TRU-L-FB-01-034	Pressure Belt Support A
46	TRU-L-FB-02-006	Tube Holder
48	TRU-L-FB-02-004	Tube Base

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB | Tube Structure & Conveyor By Acasi Machinery

Front and Back Labeler Model Tru-Labeler-FB | Parts

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB | Tube Structure & Conveyor

Item	Part No.	Part Name
2	CV-COM-01-004	Width Adjust Shaft
4	TRU-L-FB-03-040	Outer Support
6	TRU-L-FB-03-008	Conveyor Part B
8	TRU-L-W-01-014	Polyethylene wear strips color for CV 118in
10	DHP-H820-K450	Assembly Plastic Straight Running Chain 118in
12	TRU-L-W-01-020	PVC Spacer
14	DHP-H820-T21-NO	Idler Wheel Plastic Sprocket, Bore 1in
16	CV-COM-01-010	U Joint Shaft
18	TRU-L-FB-03-010	Conveyor Part A
20	TRU-L-W-01-004	Stainless Steel Spacer

Item	Part No.	Part Name
22	TRU-L-FB-03-028	Outer Support
24	TRU-L-W-01-006	Sensor Holder
26	TRU-L-W-01-038E	Support Sensor G6
28	SICK GL6-P4112	Miniature Photoelectric Sensor G6
30	CV-COM-01-08	Single Clamp
32	CV-COM-01-002	Height Adjust Shaft
34	LINA-13182	Cross Block 0.50in x 0.50in
36	PEER-77R16	Radial Ball Bearing 1 X 2 X 1/2, Shielded
38	TRU-L-W-01-018	Bearing Housing
40	TRU-L-FB-07-036	Separator
42	TRU-L-W-01-016	U Joint Shaft

Item	Part No.	Part Name
44	DHP-820-T21	Sprocket With Minimum Pilot Bore
46	TRU-L-FB-07-026	Drive Shaft- 7.5 in CV
48	LEE-WF20016301.16	520 Gear Reducers FHMQ520-26-HL-56-16
50	RRU-.5018EP3ERS56C	Motor AC, 1/2 HP, 208V, 1750 RPM, SS56C
52	TRU-L-FB-07-028	Encoder Spacer
54	TRU-L-FB-07-032	Encoder Support
56	CALT GHH60	Encoder
58	TRU-L-W-01-022	Support For Conveyor
60	GI3300-01-090	Chassis Feet
62	SW-4-POL-BASE	4 in Polymount Base

Item	Part No.	Part Name
64	100CNFHS	1-8 Hex Finish Nut S/S
66	MCM-9565K93	Protective Plug, Square Head, 3.00 in, Black
68	TRU-L-W-01-042	Bottom Cover
70	TRU-L-W-01-002E	Tube Structure Assy
72	SER-SCC-30CS420-PPUR	Caster Wheel Dia: 4
74	TRU-L-W-01-012E	Support Wheel
76	TRU-L-W-01-032E	Reflector Support
78	SICK 5304812	Reflector Standard

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB-HERMA

Main Construction Features:

Label products at speeds of 1181 in/min to 7874 in/min
Maximum label width: 13.06in
Heavy duty 304 stainless steel frame
Heavy duty casters standard
No change parts needed for a wide range of containers
Stepper driven
Labeling head for wraparound labels placed on round containers
Maximun Rolls Diameter 23.6"
Conveyor: 10ft long, 4.5” wide acetal chain with speed control installed on labeler control panel

Electric and pneumatic requirements:

100 - 240 Volts AC, 50/60Hz, 400W.

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB-HERMA | Drawing

Main Construction Features:

Label products at speeds of 1181 in/min to 7874 in/min
Maximum label width: 13.06in
Heavy duty 304 stainless steel frame
Heavy duty casters standard
No change parts needed for a wide range of containers
Stepper driven
Labeling head for wraparound labels placed on round containers
Maximun Rolls Diameter 23.6"
Conveyor: 10ft long, 4.5” wide acetal chain with speed control installed on labeler control panel

Electric and pneumatic requirements:

100 - 240 Volts AC, 50/60Hz, 400W.

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB-HERMA | Parts

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB-HH | Conveyor

Item	Part No.	Part Name
2	TRU-L-FB-07-014	Magnet
4	TRU-L-FB-07-004	Conveyor Part B
6	TRU-L-W-01-014	Polyethylene Wear Strips Color For CV 118 in
8	TRU-L-W-01-020	PVC Spacer
10	TRU-L-W-01-016	U Joint Shaft
12	CV-COM-01-010	U Joint Shaft
14	DHP-H820-T21-NO	Idler Wheel Plastic Sprocket, Bore 1 in
16	DHP-H820-K450	Plastic Straight Running Chain 118 in

Item	Part No.	Part Name
18	TRU-L-FB-07-002	Conveyor Part A
20	TRU-L-W-01-004	Stainless Steel Spacer
22	TRU-L-CONV-BR-02	Stainless Steel Conveyor Bracket
24	CV-COM-01-08	Single Clamp
26	LINA-13182	Cross Block 0.50 in x 0.50 in
28	CV-COM-01-004	Width Adjust Shaft
30	CV-COM-01-002	Height Adjust Shaft
32	TRU-L-FB-07-012-1	Reflector Base

Item	Part No.	Part Name
34	TRU-L-W-01-006	Sensor Holder
36	SICK 5304812	Reflector
38	TRU-L-W-01-032E-A	Reflector Support
40	TRU-L-FB-07-042	Support Piece
42	TRU-L-FB-07-048	Tight Seal- Strip Brushes Guide
44	TRU-L-FB-07-046	Tight Seal- Strip Brushes Support
46	TRU-L-FB-07-054	Tight Seal- Strip Brushes Support 1
48	TRU-L-FB-07-056	Tight Seal- Strip Brushes Support 2

Item	Part No.	Part Name
50	TRU-L-FB-07-050	Tight Seal- Strip Brushes Guide
52	TRU-L-FB-07-052	Tight Seal- Strip Brushes Guide
54	MCM-7442T13	Tight Seal- Strip Brushes
56	TRU-L-FB-W-H-07-006	Outer Support
58	PEER-77R16	Radial Ball Bearing, 1 x 2 x 1/2, Shielded
60	TRU-L-W-01-018	Bearing Housing
62	TRU-L-FB-07-036	Separator
64	DHP-H820-T21	Sprocket With Minimum Pilot Bore

Item	Part No.	Part Name
66	TRU-L-FB-07-026	Drive Shaft - 7.5in CV
68	LEE-W5205082.00	Worm Gear Reducer FHMQ520-26-HL-56-16
70	RRU-.5018EP3ERS56C	Motor AC, 1/2 HP, 208V, 1750 RPM, SS56C
72	TRU-L-FB-07-028	Encoder Spacer
74	TRU-L-FB-07-032	Encoder Support
76	CALT GHH60	Encoder

+ Quick View

Front and Back Labeler Model Tru-Labeler-FB-HH | Tube Structure

Item	Part No.	Part Name
2	TRU-L-W-01-012E	Support Wheel
4	TRU-L-W-01-022	Support For Conveyor
6	TRU-L-W-01-002E	Tube Structure Assy
8	MCM-9565K93	Protective Plug, Square Head, 3.00 in, Black
10	GI3100-01-090	Chassis Feet
12	100CNFHS	1-8 HEX FINISH NUT S/S
14	SW-4-POL-BASE	4 in Polymount Base
16	SER-SCC-30CS420-PPUR	Caster 4 in Wheel
