| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 2 | 692-024 | Connecting tank bracket |  |
| 4 | 692-014 |
Bar top support |
|
| 6 | ELS-77511 | Handle 7in Round | |
| 8 | GI3300-01-017 | Bottom movement stop | |
| 10 | GI3300-01-010 | Height nut 2 | |
| 12 | AEL-E2A-M12KS04-WPB1 | Height proximity sensor | |
| 14 | GI3300-01-020 | Nozzle height threaded rod | |
| 16 | GI3300-01-013 | Sensor movement top | |
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 18 | GI3300-01-012 |
Movement top |
|
| 20 | GI3100-01-004 |
Scaled height guide |
|
| 22 | GI3300-01-008 | Top bumper | |
| 24 | SKF-LJXR 20X36 ESSC2 | Calibrated shafts | |
| 26 | 692-118 | Nozzle movement support | |
| 28 | SKF-M/5201522 | 2 in linear bearing OD x 1 1/4in ID | |
| 30 | GI3300-01-019 | Bottom bumper 3 | |
| 32 | GI3300-01-016 | 1.25 linear bearing housing | |
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 34 | GI3300-01-022 |
Bottom bumper 4 |
|
| 36 | GI3300-01-034 |
Calibrated shafts bottom hold |
|
| 38 | 692-130 | Right side cover | |
| 40 | GI3300-01-026 | Nozzle holding bar | |
| 42 | M1-36677029 | Radial shaft seal 1x1.5x0.25 | |
| 44 | GI3300-01-038 | Radial shaft seal housing | |
| 46 | 692-016 | Trupiston-2-SH Nozzle holding square tube | |
| 48 | GI3300-01-015 | Bottom bumper 1 | |
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 50 | ADA-SR-125-D1 |
1-1/4 Bore air cylinders, Stainless steel rod, Stroke: 5" |
|
| 52 | GI3300-01-068 |
Gating cylinder spacing tip |
|
| 54 | 692-022 | Trupiston-2-SH Gating tube 1 | |
| 56 | 692-012E | Trupiston-2-SH Chassis | |
| 58 | ADA-SR-122-D1 | 1-1/4 Bore air cylinders, Stainless steel rod, Stroke: 2" | |
| 60 | PU7000-01-038 | Gating L 1 | |
| 62 | MAC-ACASI-SER-01 | Serial Nameplate | |
| 64 | PU7000-01-036 | Gating L 2 | |
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 66 | GI3300-01-070 |
Gating rectangles height spacer |
|
| 68 | 692-020 |
Chassis cover |
|
| 70 | 610-250 | Right conveyor bracket | |
| 72 | 610-240 | Left conveyor bracket | |
| 74 | HPE-AS3201FN0307SX35 | Inline flow control, panel mount 12mm | |
| 76 | ADA-922B-RA | Valve Mac 922B-RA | |
| 78 | SMC-NCAY5EO006B1000 | Air cylinder 2.5 bore, 10 in stroke | |
| 80 | 692-102-3 | Top plate | |
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 82 | 692-128 |
Back bottom cover |
|
| 84 | 692-126 |
Left side cover |
|
| 86 | 692-010E | Trupiston-2-SH Tube structure | |
| 88 | AME-HNMX-16 | Hexagon nut M16x2 | |
| 90 | GI3100-01-138 | Pump base leg | |
| 92 | 692-132 | Front cover | |
| 94 | ELS-301251 | Levelling base | |
| 96 | 692-134 | Valve support plate | |
| 98 | ADA-6532B-241-RA | 4 way valve 1/2" port | |
