ELEVATION SYSTEM & ELECTRICAL PANEL
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 2 |
NOF-0.375-01-023 |
Washer, ID 0.406in, OD 1.250in |  |
| 4 | LEE-W5200082 | Single reduction 520 Series, Ratio 26 | |
| 6 | LEE-G175210 | Flange B for Worm drive gear box | |
| 8 | CF4400-01-040 | Motor spacer | |
| 12 | CF4400-01-006 | Drive shaft | |
| 14 | CF4400-01-008 | Movement belt sprocket, 12 teeth | |
| 16 | M1-86899341 | Shaft collar 1in ID, 1.625in OD | |
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 18 | KVP-7F10SWP0180P0 | Band HDS61000 Series, Nominal 18in | |
| 20 | CF4400-01-014 | Wear strip 1 | |
| 22 | CF4400-01-016 | Wear strip plate | |
| 26 | CF4300-03-106 | Height threaded rod | |
| 28 | CF4400-01-022 | Back cover 2 | |
| 30 | CF4400-01-060 | Pillow block plate | |
| 32 | SKF-FYT 1 RM | Pillow block flange 1in 2 hole | |
| 33 | CF4400-01-052 | Hopper right 1 | |
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 34 |
LEE-098000 |
DC Motor 0.5 Hp, 1750 RPM. | |
| 35 | CF4400-01-012 | Air block | |
| 36 |
CF4400-01-124 |
Belt guide right 3 | |
| 38 |
CF4400-01-042 |
Wear strip plate support 1 | |
| 40 | CF4400-01-020 | Side guide | |
| 42 | CF4400-01-046 | Spacing shaft 1 | |
| 44 | CF4400-01-018 | Acrylic bracket | |
| 46 | CF4400-01-126 | Structure right 1 | |
| 48 | CF4400-01-122 | Hopper back cap | |
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 50 |
CF4400-01-132E |
Belt tensioning screw | |
| 52 | BU7000-09-038 | Tensioning bracket | |
| 54 | CF4400-01-128 | Tensioning collar | |
| 56 | CF4400-01-112 | Hooper left 1 | |
| 58 | SOL-VG-634-AA | Heavy Duty Hinge | |
| 60 | CF4400-01-084 | Inclined acrylic | |
| 62 | CF4400-01-050 | Front acrylic 1 | |
| 64 | CF4400-01-010 | Acrylic fixed A | |
| 66 | CF4400-01-044 | Acrylic hold | |
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 68 | CF4400-01-118 | UHMW guide 1 | |
| 70 | CF4400-01-120 | UHMW guide 2 | |
| 72 | CF4400-01-090 | Hooper right 2 | |
| 74 | CF4400-01-004 | Structure left 1 | |
| 76 | CF4400-01-094 | Idler shaft | |
| 78 | CF4400-01-096 | Idler belt sprocket, 12 teeth | |
| 80 | CF4400-01-088-new | Acrylic cap hopper 1 | |
| 82 | M1-82504721 | Straight handle of 5in | |
| 84 | CF4400-01-086E | Holder acrylic | |
| 86 | CF4400-01-092 | Acrylic cap hopper 2 | |
| Item | Part No. | Part Name | Price |
|---|---|---|---|
| 88 |
CF4400-01-102 |
Wear strip support | |
| 90 | CF4400-01-104 | Wear strip lip | |
| 92 | CF4400-01-110E | Tube structure | |
| 94 | CF4400-01-114 | Hooper left 2 | |
| 96 | CF4400-01-100 | Front plate protector | |
| 98 | CF4400-01-098 | Hooper front plate | |
| 100 | ELS-978621 | Handwheel OD: 4.92in, 2 spoke | |
| 102 | CF4300-01-030 | Pivot screw | |
| 104 | CF4300-01-034 | Leg 2 | |
| 108 | CF4400-01-116 | Leg 1 | |
| 110 | ELS-301251 | Reinforced base | |
